Features
● The 45mm quiet roller rail is wider than the 35mm wire gauge on the market, which has strong bearing capacity, good resistance to distortion, and no deformation in heavy cutting.
● The machine adopts herringbone wide column structure, increasing the column stability, making the processing performance more stable.
● 6 sliding blocks are used in X and Z axes, which makes the force surface larger and the bearing capacity stronger.
● The Z-axis is equipped with six heavy-duty enhanced sliders and BT40 rigid spindle, providing a cost-effective machine tool for the processing of hardware and plastic molds.
● Widely used in machining, auto parts, lighting, hardware, aerospace, military, communications and medical equipment and other industries of product processing
The VM Series CNC Vertical Machining Centers are high-performance, high-stability CNC machines specifically engineered for high-precision milling, drilling, tapping, and boring of complex components. Featuring a modular design, this series offers excellent rigidity and dynamic performance, capable of handling a wide range of machining needs—from small and medium-sized parts to large workpieces. The VM series Vertical Machining Center is widely used in industries such as mold making, aerospace, automotive manufacturing, and energy equipment production.
High-Rigidity Structural Design:
The machine base is made from high-quality cast iron and optimized through finite element analysis (FEA) for superior vibration resistance and thermal stability. All three axes utilize high-precision linear guides, with the Z-axis equipped with a counterbalance system to minimize vibration during high-speed operation, ensuring long-term machining accuracy.
High Precision and Dynamic Performance:
Repeatability: ±0.003 mm per 300 mm, ideal for precision mold making and complex surface machining.
Spindle speed ranges from 8,000 to 12,000 RPM with high torque, suitable for both heavy-duty roughing and high-speed finishing.
Smart & Automation Ready:
Equipped with the latest CNC systems (Mitsubishi, FANUC, or advanced domestic controllers).
Optional support for 4-axis or 5-axis simultaneous machining (with optional rotary table).
24-tool Automatic Tool Changer (ATC) with a 1.4-second tool change time for enhanced continuous machining efficiency.
Integrated automation interfaces for robotic arms or conveyor systems, enabling fully unmanned operation.
| Item | unit | VMC-856 |
| Worktable area | mm | 1000*550 |
| Worktable maximum loading | kg | 600 |
| T-Slot(slot*width*distance) | mm | 5-18*90 |
| Spindle nose taper | BT | BT40 |
| XX/Y/Z axis travel | mm | 800/560/560 |
| Distance between spindle end face and worktable end face | mm | 120-670 |
| Specifications of X, Y and Z axle guideways | mm | 35/45/45 |
| Spindle Speed (Belt type/Direct Connection) | rpm | 10000/12000 |
| Tool magazine capacity | T | 24 |
| X/Y/Z axis fast displacement | m/min | 48*48*48 |
| Cutting feed speed | m/min | 1-8000 |
| Repeated positioning accuracy | mm | ±0.003/300 |
| Machine weight | Kg | 5000 |
*As our company is constantly improving its products, we reserve the right to change the design, specifications and configuration at any time without prior notice. If you patronize us, please confirm whether the specifications have changed! Contact immediately.
Metallic Materials: Aluminum, steel, stainless steel, titanium alloys, cast iron, etc.
Non-Metallic Materials: Composite materials, nylon, bakelite, graphite, and more.
Milling: Flat surfaces, profiles, 3D contours, helical grooves, and other complex geometries
Drilling/Boring: High-precision hole processing, φ0.5 mm to φ150 mm diameter range
Tapping: Supports M3–M30 threading, compatible with both rigid and floating tapping
Chamfering/Deburring: Capable of integrating automated deburring solutions
Typical Travel Range (X/Y/Z): 800×550×560 mm to 1300×700×700 mm (depending on model)
Max Workpiece Weight: 600–900 kg (depending on model)
● The 45mm quiet roller rail is wider than the 35mm wire gauge on the market, which has strong bearing capacity, good resistance to distortion, and no deformation in heavy cutting.
● The machine adopts herringbone wide column structure, increasing the column stability, making the processing performance more stable.
● 6 sliding blocks are used in X and Z axes, which makes the force surface larger and the bearing capacity stronger.
● The Z-axis is equipped with six heavy-duty enhanced sliders and BT40 rigid spindle, providing a cost-effective machine tool for the processing of hardware and plastic molds.
● Widely used in machining, auto parts, lighting, hardware, aerospace, military, communications and medical equipment and other industries of product processing
Mold Making: High-precision processing of mold cores, bases, and inserts for injection molds, die-casting molds, and stamping dies
Aerospace: Five-face machining of aircraft structural parts, engine components, and landing gear made from high-strength alloys
Automotive: Efficient machining of key components such as transmission housings, engine blocks, EV battery cases, and steering knuckles
Energy Equipment: Precision milling of large workpieces like wind turbine gearboxes, hydraulic manifolds, and turbine blades
Medical & Optics: High-precision machining of implant frames, optical barrels, and laser device components requiring superior surface finish
With exceptional rigidity and operational flexibility, the VM Series Vertical Machining Centers deliver reliability and precision for even the most demanding manufacturing environments.
